FEATURE SPECIFICATION
Dimensions 310 x 310 x 550 mm (ex. support)
Weight 16kg (39kg inc. field support)

Environmental rating IPX6

Temperature range -10° to +50°C

Humidity 95% non-condensing
Antenna 1 gain 18 dBi
Antenna 2 gain 18 dBi
Polarization Cross
Maximum transmission power radio 4W
Frequency range radio 2200 – 2500MHz
Bandwidth 20MHz
Input Ethernet + 30VDC (>100W)
Connection port types ODU AMC
Output port Ethernet + 20VDC (SRA)
