Pisces Harsh Environment Waterproof Products
)
Intelliconnect (Europe) Ltd the UK based specialist manufacturer of RF connectors announces the availability of its wide range of IP67 and IP68 interconnect solutions for harsh environments. Qualified to withstand immersion at a minimum of 20m for four hours in their unmated condition, the Pisces range are renowned for reliability under rigorous conditions and Intelliconnect are now widely considered to be the world leaders in this highly specialised field.
Intelliconnect Pisces waterproof RF connectors are suitable for many applications including: high quality Antennas, Personal Locator Beacons, Cochlear Implant devices, petrochemical monitoring equipment, and traffic indication systems.
Pisces waterproof RF connector designs are available for most Coaxial/Triaxial/Twinaxial waterproof connector groups. Standard models include high frequency waterproof connectors, to both commercial and MIL standards, including SMA, TNC, N, SMB and push-pull connector types.
Intelliconnect Pisces connectors are waterproof, mated or unmated, for a minimum 4 hours at 20m depth and are available on short lead-times and offer complete flexibility to meet customer requirements, with custom designs available within 24 hours.
All Pisces connectors are designed to meet the requirements of US MIL-PRF-39012, MIL-STD-348 and IEC: 169-8. Waterproofing meets IP68 per IEC 60529, (NEMA 6P or better), tested to a 20 meter water depth in an unmated condition for duration of 4 hours. Operating temperature range is -65°C to +165°C, corrosion (salt spray) performance is to MIL-STD-202, Method 101 and moisture Resistance is to MIL-STD-202, Method 106.
